Brief Introduction of Bone Crusher Machine
The commercial animal bone crusher machine is a powerful processing equipment. It is mainly used to crush dry, fresh and frozen bones into pieces of different sizes and tear animal skins. At the same time, the equipment can also crush Chinese medicine, five spices and other products. bone crusher machines are usually made of sturdy materials to ensure that they can withstand high-intensity work. It is equipped with multiple sets of sharp knives and a powerful power system to quickly and effectively crush various bones. In addition, the Gondor animal bone crusher machine is easy to operate, safe and reliable, and has a high crushing efficiency. Because of its wide range of output differences, it is suitable for a variety of people such as individual business operators and food processing plants.
| Model | 180 | 300 | 400 | 500 | 600 | 800 | 1000 |
| Feed size(mm) | 180*190 | 310*210 | 420*230 | 520*250 | 620*320 | 820*650 | 1100*800 |
| Material handling dimensions(mm) | 4-30 | 4-50 | |||||
| Yield(kg/h) | 20-60 | 80-200 | 150-400 | 200-600 | 300-900 | 800-2500 | 1000-4000 |
| Power(kw) | 3 | 5.5 | 7.5 | 11 | 15 | 30 | 45 |
| Voltage(v) | 380 | ||||||
| Weight(kg) | 160 | 340 | 420 | 600 | 800 | 2000 | 3800 |
| Screen aperture(mm) | 5-50 | 5-80 | 5-100 | ||||
Efficient Working Principle of Commercial Animal Bone Crusher Machine
The high efficiency of Gondor animal bone crusher machine stems from its scientific crushing principle. After the material enters from the double-layer inlet, it is not simply “smashed”, but goes through a process of cutting and grinding. The high-speed rotating alloy steel blade shears the bone initially, and then the crushed material collides and rubs with the customizable screen in the cavity until the particles are smaller than the screen aperture and then discharged. This design ensures the uniform and controllable discharge size, and gives full play to the potential of bone crushing machine as precision machining equipment.
Application Market Scope of Gondor Bone Crusher Machine
- Crush bones into suitable sizes for making products such as bone broth and bone meal.Meat Processing
- Processed bones are used as an ingredient in pet food to provide calcium and nutrition.Pet Food Production
- Crush the bones into feed additives to increase the nutritional content of the feed.Feed Industry
- Used to extract collagen and other ingredients from animal bones for the production of cosmetics and health products.Chemical Industry
- Crushing organic waste such as animal bones facilitates subsequent harmless treatment and resource utilization.Environmental Protection Field
- In biological and medical research, crushed bones are used for sample analysis and experiments.Scientific Research Field
- Large-scale processing of bones, production of various bone powder products, such as agricultural bone powder, etc.Bone Powder Production Enterprises
Unique Mechanical Characteristics of Gondor Animal Bone Crusher Machine
Meat Processing
With high-power motor and multiple sets of blades for cutting and crushing, it can easily handle bones of various hardness and sizes.
Customized Screen
Special material door device and screen hole size can be designed according to the actual situation of customers.
Double-layer Feed Inlet
Double-layer 304 stainless steel wide inlet, convenient and fast feeding, clean, and good sound insulation effect.
Stable Performance
The whole machine is made of 304 stainless steel and copper core motor, which makes the machine’s working performance more stable.
Multiple Sets of Blades
Blades is made of SKD-11 special heat-treated alloy steel, which is sharp and durable.
Easy-to-Maintain Structure
Reasonable design, easy disassembly and installation of key components, convenient daily maintenance and maintenance.
Choosing the Right Bone Crusher for Your Business
There are several key factors to consider when choosing a suitable bone crusher machine. First of all, make clear your throughput requirements: is it individual processing in small batches or continuous mass production? Secondly, choose the corresponding motor power and blade configuration according to the type of bone you mainly deal with (such as hard bracket bone or smaller bird bone). An animal bone crusher machine with matching performance is the basis of improving efficiency, reducing energy consumption, and maintenance costs.
Gondor Commercial Animal Bone Crusher Machine – Efficient Crushing Expert
Choosing Gondor animal bone crusher machine means you gain not just a piece of equipment, but a trusted partner. We understand that a reliable bone crusher is crucial for the continuity of your production line. Therefore, we provide comprehensive technical guidance, timely parts supply, and a professional after-sales support network to ensure your equipment always operates at peak performance, safeguarding your business growth.
